Brackets

H318S
Single sign clamp for 2" round posts, holds one sign - 2 per sign

HTSA2X116
Sign clamp for 2" round post' holds one sign - 2 per sign

H318D
Double sign clamp for 2" round post; holds 2 signs mounted back to back - 2 per sign

HBR4
Bracket for round post, will hold one or two signs mounted back to back - 2 per sign

H606F2
Round cap for 2" post, flat blades with 3 1/4" blade holder

H606F90
90° Crosspiece, for flat blades with 3 1/4" blade holder

H606F45
45° Crosspiece, for flat blades with 3 1/4" blade holder

H606FU90
U-Channel Cap with bolts, sits 90° to flange on post; for flat blades with 3 1/4" blade holder

H606FU180
U-Channel Cap with bolts, sits 180° to flange on post; for flat blades with 3 1/4" blade holder

H707EX2
Round cap for 2" post, for extruded blades with 3 1/4" blade holder

H707EX90
90° Crosspiece, for flat blades with 3 1/4" blade holder

H707EX45
45° Crosspiece, for flat blades with 3 1/4" blade holder

H707EXU90
U-Channel Cap, 90° to flange on post; for extruded blades with 3 1/4" blade holder

H707EXU180
U-Channel Cap, 180° to flange on post; for extruded blades with 3 1/4" blade holder

H808F2
Round cap for 2" post, for flat blades with 5 1/4" blade holder

H808EX2
Round cap for 2" post, for extruded blades with 5 1/4" blade holder

H808F90
90° Crosspiece, for flat blades with 5 1/4" blade holder

H808EX90
90° Crosspiece, for extruded blades with 5 1/4" blade holder

45° Crosspiece available for flat and extruded blades

H808FU90/H808EXU90
U-Channel Cap with bolts, sits 90° to flange on post; for flat/extruded blades with 5 1/4" blade holder

H808FU180/H808EXU180
U-Channel Cap with bolts, sits 180° to flange on post; for flat/extruded blades with 5 1/4" blade holder

H809EXVP2
Round cap for 2" post, for flat or extruded blades, 6" blade holder for superior sign holding strength

U-Channel cap and 90° Crosspiece also available

H812F2
Round cap for 2" post, for flat blades with 12" blade holder

H812EX2
Round cap for 2" post, for extruded blades with 12" blade holder

H812F90
90° Crosspiece, for flat blades with 12" blade holder

H812EX90
90° Crosspiece, for extruded blades with 12" blade holder

Style H850
2" x 2" Square cap for flat or extruded blades in 2 sizes

H850FS2
3 1/8" blade holder
H850FL2
5 1/4" blade holder
H850EXS2
3 1/8" blade holder
H850EXL2
5 1/4" blade holder

H827F/H827EX
Square cap for flat or extruded blades, 3 1/2" blade holder for 4" x 4" wood post. Normally mounted on top of post but may be mounted on side to be used as a cantilever bracket

H909EXVP2
Round cap for 2" post with flat or extruded blades 6" blade holder and tapped on 4 11/16" centers, bolt thru application only

U-Channel cap and 90° crosspiece available

H721F
Wing bracket for flat blades, 4 1/16" long. Can be secured to posts with metal strapping or by bolting through two countersunk holes

H7309
Wing bracket for extruded blades with hardware, 9" blade

H730675
Wing bracket for extruded blades with hardware, 6 3/4" blade

H7306
Wing bracket for extruded blades with hardware, 6" blade

H1010
Cantilever Arm bracket for flat or extruded blades, 14 1/2" long

H1010EXT
Cantilever Arm Bracket extension for flat or extruded blades, 14 1/2" long. Total length with extension is 29"

PACSB200SQS-Z
Short Cantilevered Saddle Bracket for 2" Telespar post

PACSB200SQL-Z
Long Cantilevered Saddle Bracket for 2" Telespar post

PACSB450RDL-Z
Long Cantilevered Saddle Bracket for 4 1/2" or larger round post

PACSB450RDS-Z
Short Cantilevered Saddle Bracket for 4 1/2" or larger round post

HHEN6
Mounting bracket for 6" extruded street sign

HHEN9
Mounting bracket for 9" extruded street sign

HHEN12
Mounting bracket to hold sign at 45° angle; intended for parking signs

HHEN9S
Mounting bracket for 9" extruded blade street sign, to be used with 2" square posts
